WESAUDIO

ng76 Stereo Pair

$4,125.00 CAD
Request a Quote – For Authorized Dealers Only

Description

True Stereo Operation

  • Two ng76 mono compressors can be linked via dedicated software.
  • Link compression detectors using special cables (included with stereo-matched pairs) for true stereo compression.
  • Option for dual mono compression with all parameters linked across both units.
  • Any changes made on one unit will be automatically reflected on its paired twin.
    •

    Features

    • 100% analog FET compressor with +24dBu of headroom.

    • Link two mono channels through dedicated software for stereo use.

    • Classic lightning-fast compression based on the WesAudio Beta76 design.

    • Flexible DAW/Live plug-in control for instant recall.

    • MIX knob for easy parallel compression.

    • Carnhill transformers for both input and output stages.

    • Saturation mode for special saturation/clipping effects based on the FET circuit.

    • Supports all ratio combinations, including ALL BUTTON MODE.

    • Modern and Vintage modes for two 1176 revisions (F & G).

    • Two independent sidechain EQ circuits for versatile control.

    • THD control with LOW and HIGH settings for total harmonic distortion based on the FET circuit.

    STEREO MATCHED PAIRS:

    • Includes two separate mono-channel devices that can be linked together through dedicated software.

    • Compression detectors can be linked for true stereo compression using a dedicated cable (included).

    • All parameters between the units are synchronized via a dedicated plug-in.

    • Factory settings ensure the units are fully matched for stereo usage right out of the box.

    Specifications

    Attack time: 20 us - 800 us

    Release time: 50 ms - 1100 ms

    Compression ratio: 4:1; 8:1; 12:1; 20:1; all button mode and all combinations True Bypass

    SC High Pass filter: 60,90,150Hz

    SC High Shelf filter: 2KHz, 5KHz, 10kHz

    Output impedance: 50 ohm

    Frequency response: 20Hz to 20kHz (+/- 1dB)

    Signal to noise ratio SNR: SNR >83dB

    Max signal level: +24dBu

    THD+N MIN: 0.2%

    Noise floor: -95dBu

    Power consumption: 8W

    Dimensions: 88x483x235mm

    Weight: 6 kg

    Balanced output and input:

    Case Rack: 2U
