TUBE-TECH  |  Barcode: LCA 2B

LCA2B

$7,290.00 CAD

Description

This kind of compressor is also known as a Vari Mu compressor. TUBE-TECH LCA 2B is one of the most powerful and versatile VCA compressors in the market. LCA 2B is extremely versatile, and it works equally well on vocals, instruments and as a bus compressor. Due to its very fast and smooth attack, it is also perfect for drums and percussion.

There's literally nothing the LCA 2B can't handle very well: Powerful bus compression (it's a dream used for bus compression both inserted and in parallel.) and fine single instrument and voice compression. The action of the LCA2B is always easy to hear, so finding the right setting on this compressor is a not complicated.

LCA2B is designed to be the TUBE-TECH equivalent of the Fairchild 670, but only in terms of action, not the actual electronics. It is designed with the Fairchild in mind, delivering similar action but retaining its transparency or high frequencies, even when pushed to the limit). The fixed attack/release constants are duplicates of the Fairchild constants.

When you want even more control, power and wildness than our famous CL1B can deliver, try the LCA 2B that has found good use in many top live engineers' touring racks.

Specifications

General

Tube VCA compressor/limiter

All-tube based push-pull amplifier

Frequency response @ -3 dB: 5 Hz to 50 kHz

Low noise: < -85 dBU @ 10 dB gain

CMRR: > 60 dB @ 10 kHz

Separate compressor and limiter

Output Gain: -6 dB to +10 dB

Interconnection of several compressors via two busses

Clickless In/Out relay

Conductive plastic potentiometers

Gold plated switches

Inputs and outputs are transformer balanced and fully floating

Linkable for stereo applications

Compressor

Variable ratio (1.6:1 to 20:1)

Variable threshold (Off to -20 dBU)

Continuously variable attack and release times

Choice between 6 presets (Fairchild) and manual attack/release control

LED Gain reduction display

Limiter

Variable threshold (Off to 0 dBU)

Attack: 0.8 ms - release: 0.5 sec

Separate Limiter On/Off switch

LED indication of limiter action
