ELYSIA

Karacter

$2,080.00 CAD

Description

On top of everything the 500 series module has to offer, the amazing special feature of the rack version is its CV capability: By feeding external control voltages into the karacter it is possible to modulate or recall its Drive and Mix parameter settings. Analog synth, MIDI-to-CV interfaces and many other kinds of sources can be used to feed the karacter with oscillators, value sweeps and setup changes.

Features

100% DISCRETE CLASS-A TOPOLOGY:

Expensive boutique sound made affordable.

MASTERING-GRADE SATURATION:

Gentle THD generation with a soft characteristic.

TUBE-INSPIRED DISTORTION:

Wide ranges of asymmetrical low noise clipping.

GLORIOUS DESTRUCTION:

Turbo Boost for massive sonic mayhem.

BULLETPROOF LIGHTWEIGHT:

Aluminum housing, panel and knobs.

CONTROL VOLTAGE:

Modulation and recall of Drive and Mix.

COLOR FILTER:

Harmonics-frequency relation tweaks.

DUAL MONO/STEREO LINK/MID SIDE:

Signal matrix for maximum flexibility.

STEPPED CONTROLLERS:

Fast and easy recall guaranteed.

MADE IN GERMANY:

Build quality without compromise.

Specifications

FREQUENCY RESPONSE:

• 100% Dry: < 10 Hz - 400 kHz (-3 dB)

• 100% Wet: < 10 Hz - 27 kHz (-3 dB)

THD+N - 100 % DRY:

• @ 0 dBu: 0.013 %

• @ +10 dBu: 0.024 %

THD+N - 100 % WET (IN SATURATION MODE):

• @ 0dBu Min Drive: 0.47 %

• @ 0dBu Max Drive: 35.1 %

NOISE FLOOR - 20HZ - 20KHZ (A-WEIGHTED):

• 100% Dry: -91 dBu

• 100% Wet (depending on Drive and Gain): -81 to -91 dBu

DYNAMIC RANGE:

• 20 Hz - 22 kHz: 112 dB

MAXIMUM LEVEL:

• Input: +21 dBu

• Output: +21 dBu

IMPEDANCE:

• Input: 10 kOhm

• Output: 68 Ohm
