ELYSIA | Code-barres: 994046001

Karacter

Name: Karacter
Brand: ELYSIA
SKU: 12918
Price: 2080.00 CAD
Availability: InStock

$2,080.00 CAD

1 in stock

Demande de devis – Réservé aux revendeurs agréés

Can't find the product you're looking for?

Description

On top of everything the 500 series module has to offer, the amazing special feature of the rack version is its CV capability: By feeding external control voltages into the karacter it is possible to modulate or recall its Drive and Mix parameter settings. Analog synth, MIDI-to-CV interfaces and many other kinds of sources can be used to feed the karacter with oscillators, value sweeps and setup changes.

Spécifications

Frequency response

100% Dry: < 10 Hz - 400 kHz (-3 dB)

100% Wet: < 10 Hz - 27 kHz (-3 dB)

THD+N - 100 % Dry

@ 0 dBu: 0.013 %

@ +10 dBu: 0.024 %

THD+N - 100 % Wet (in Saturation Mode)

@ 0dBu Min Drive: 0.47 %

@ 0dBu Max Drive: 35.1 %

Noise floor - 20Hz - 20kHz (A-weighted)

100% Dry: -91 dBu

100% Wet (depending on Drive and Gain): -81 to -91 dBu

Dynamic range

20 Hz - 22 kHz: 112 dB

Maximum level

Input: +21 dBu

Output: +21 dBu

Impedance

Input: 10 kOhm

Output: 68 Ohm

EAN: 4251203700129
