WESAUDIO

ng76 Fet

$2,065.00 CAD

Description

Next generation FET compressor with digital recall and automation

FET compressors have been an essential tool in recording studios for over 50 years. Its distinctive sound and reliability have made it a go-to for producers and engineers around the world. The 76-style FET compressor has left its mark on countless hit records which has helped to establish its reputation as a reliable and versatile tool in the recording technology. We have improved this design, creating a whole new level of versatility with seamless DAW integration - We present ng76 - fully analog FET compressor with digital recall.

Features

• 100% analog FET compressor with 24dBu of headroom

• 2 x mono-channel devices can be linked together through dedicated software

• Classic lightning speed compression style based on WesAudio Beta76 design

• Flexible DAW/Live plug-in control for instant recall

• MIX knob for parallel compression

• Carnhill Transformers (input and output)

• Saturation mode - Special saturation / clipping mode based FET circuit

• All ratio combinations including ALL BUTTON MODE!

• Modern and Vintage modes to support two 1176 revisions (F & G)

• Two independent side chain EQ circuits

• THD - total harmonic distortion with LOW and HIGH settings based on the FET circuit

Specifications

Attack time: 20 us - 800 us

Release time: 50 ms - 1100 ms

Compression ratio: 4:1; 8:1; 12:1; 20:1; all button mode and all combinations True Bypass

SC High Pass filter: 60,90,150Hz

SC High Shelf filter: 2KHz, 5KHz, 10kHz

Output impedance: 50 ohm

Frequency response: 20Hz to 20kHz (+/- 1dB)

Signal to noise ratio SNR: SNR >83dB

Max signal level: +24dBu

THD+N MIN: 0.2%

Noise floor: -95dBu

Power consumption: 8W

Dimensions: 88x483x235mm

Weight: 6 kg

Balanced output and input:

Case Rack: 2U
